Category: Silicone roller

Silicone Roller

Custom silicone rubber rollers for heat transfer, corona treatment, cast-film, packaging and industrial machinery.

Model	Product	Temperature	Max. Diameter	Max. Length	Hardness	Application
GRFFN9501	200°C Silicone Roller	200°C	1,000 mm	6,000 mm	40-90 Shore A	General industrial equipment
GRFFN9502	260°C Silicone Roller	260°C	600 mm	6,000 mm	40-90 Shore A	General industrial equipment
GRFFN9503	300°C Silicone Roller	300°C	600 mm	6,000 mm	40-90 Shore A	High-temperature equipment
GRFFN9504	Heat-Transfer Silicone Roller	300°C	600 mm	6,000 mm	70-90 Shore A	Hot stamping and heat transfer
GRFFN9505	Corona Silicone Roller	260°C	600 mm	6,000 mm	60-80 Shore A	Corona treatment machines
GRFFN9506	Liquid-Cast Silicone Roller	300°C	600 mm	6,000 mm	0-80 Shore A	Cast-film machines
GRFFN9507	Oil-Resistant Silicone Roller	200-260°C	600 mm	6,000 mm	40-90 Shore A	Industrial processing
GRFFN9508	Anti-Stick Silicone Roller	220°C	600 mm	6,000 mm	40-90 Shore A	Packaging and processing
GRFFN9509	Dust-Removal Silicone Roller	220°C	600 mm	6,000 mm	0-60 Shore A	Surface cleaning
GRFFN9510	Custom-Shaped Silicone Roller or Wheel	200-300°C	1,200 mm	6,000 mm	0-90 Shore A	Custom industrial equipment

Custom Industrial Silicone Rubber Rollers

GRFFN manufactures silicone rubber rollers for packaging, printing, heat transfer, corona treatment, cast-film production, food-processing equipment, electronics and industrial machinery. Roller compounds and coverings are selected according to temperature, hardness, release, oil resistance and surface requirements.

Manufacturing Range

Roller diameters up to 1,200 mm, depending on model
Roller lengths up to 6,000 mm
Hardness from 0 to 90 Shore A
Temperature resistance from 200°C to 300°C
Heat-transfer, corona, cast-film, oil-resistant, anti-stick and dust-removal options

Quotation Information

Please provide the roller drawing, metal-core dimensions, finished diameter and length, hardness, working temperature, surface finish, operating speed and application.
